pBluescript Plasmids
pBluescript Plasmids are commonly used vectors in molecular biology for cloning and expression experiments. They are derivatives of the original pUC plasmid vector system, modified to include additional features for various applications.
Key Features
- Origin of Replication (ori): The plasmid contains the pUC ori which allows for high copy number replication in E. coli, typically producing 100-300 copies per cell.
- Selectable Marker: The vector includes an ampicillin resistance gene (bla), providing antibiotic resistance to ampicillin. This marker allows for the selection of successfully transformed cells in the presence of ampicillin.
- Multiple Cloning Site (MCS): The MCS, located within the lacZα gene, provides multiple unique restriction enzyme sites for the insertion of foreign DNA. This site is strategically placed to facilitate cloning of DNA fragments while minimizing disruption to the vector’s essential functions.
- LacZα Complementation: The plasmid carries a portion of the lacZ gene (lacZα). Insertion of a DNA fragment into the MCS disrupts the lacZα gene, which can be used for blue/white screening. Cells with an insert appear white, while cells without an insert appear blue when grown on X-gal and IPTG media.
- Promoter Elements: pBluescript vectors typically include strong promoter elements such as the T7 and T3 promoters for transcriptional initiation, allowing for in vitro transcription applications.
- T7 and T3 Transcriptional Control: The plasmid has T7 and T3 RNA polymerase promoters flanking the MCS, facilitating high-yield transcription of cloned genes in systems where T7 or T3 polymerases are available.
- Size and Features: The plasmid backbone is generally about 3.0-3.5 kb in length, with features designed to ensure ease of use and versatility in cloning and expression applications.
Content:
- Backbone: ~3.0-3.5 kb plasmid DNA.
- Genes:
- Ampicillin resistance gene (bla).
- LacZα fragment.
- Promoters:
- T7 promoter.
- T3 promoter.
- Multiple Cloning Site (MCS): Contains various restriction sites for insertion.
Applications:
- Cloning: Facilitates the insertion of DNA fragments for cloning purposes.
- Expression Studies: Useful for studying gene expression under the control of T7 or T3 promoters.
- Blue/White Screening: Enables differentiation of recombinant colonies from non-recombinant colonies.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
